Gross Power: | 500W | Color & Page: | Single Color |
---|---|---|---|
Usage: | Paper Printer | Plate Type: | Flatbed Printer |
Condition: | New | Dimensions(L*W*H): | 220cm*40cm*50cm |
Weight: | 84kg | Automatic Grade: | Automatic |
Voltage: | 110V/220V | Ink Type: | Water Based Ink |
Print Head: | HP 45 Head * 2 | Print Interface: | Network Interface/USB |
Paper Weight: | 25g-120g | Print Speed: | 60 Meters Long/hour |
Max Paper Width: | 2200mm | Max Drawing Width: | 2100mm |
Input Voltage: | AC110V/220V | Input Power: | No Less Than 400W |
Type: | Digital Printer | After-sales Service Provided: | No Overseas Service Provided |
Port: | Shanghai/Ningbo | ||
High Light: | garment plotter machine,inkjet clothing printer |
- Plotting head uses popular HP technology, easy for maintenance.
- Advanced design theory, scientifically, practically and precise manufactured, with high stability and operant.
- Automatic ink carriage clearing.
- Occupied small place in the pattern room.
- High speed, long time working, without any compromise on the quality and the reliability.
- Supports DMPL and HPGL language, fully supports for various CAD software.
Item
|
printing machine
|
Color &Page
|
Single Color
|
Voltage
|
110v/220v
|
Ink type
|
Water Based Ink
|
Automatic Grade
|
Automatic
|
Print Interface
|
Network interface/USB
|
Drive
Digital high-speed servo control, full closed loop positioning.
Unique built-in cartridges, to make the maximum format of printing area.
SPECIFICATIONS ABOUT OUR INKJET PLOTTER
|
||||
Type
|
TJ12
|
TR/TF/TX19
|
TR/TF/TX21
|
TR/TF/TX23
|
Maximum paper width
|
1300mm
|
2000mm
|
2200mm
|
2400mm
|
Maximum drawing width
|
1150mm
|
1900mm
|
2100mm
|
2300mm
|
Number of print cartridge/Type
|
Dual Spray/HP generic ink cartridges HP45/6145A
|
|||
Driving
|
Digital high-speed servo control,full closed loop positioning
|
|||
Resolution
|
150-600DPI (Toner Save Mode Optional)
|
|||
Print speed
|
800-120m²/Bidrectional
|
|||
Command format
|
HP-GL
|
|||
Communication port
|
USB/Network printing
|
|||
Software platform
|
Windows XP, Windows 7, Windows 8, Windows 10
|
|||
Nozzle cleaning
|
Automatic cleaning function
|
|||
Close feed
|
Front automatic admission feeder system,saving paper loading time
|
|||
Enrirnomental Requirements
|
Temperature of 10℃-35℃ Humidity RH15-85%(no condensation)
|
|||
Input Voltage
|
AC220V/60hz power of not less than 400W (AC110V optional)
|
Our quality control system & Products' quality approved by CE & ISO
Q: What is the application of these inkjet potter, inkjet cutter plotter and flatbed cutter plotter?
A:These plotter are applied to garment pattern printing and cutting. You can draw the pattern in software, and then print them on paper. If you need to cut the pattern along printing line, it also can.
Q:How many printing heads does it have? Do you have pen plotter?
A:It has two heads. We have stopped to manufacture pen plotter. But if you really want, we can provide it for you.
Q:Is your plotter compatible with Gerber? I don’t have the software, can I use it?
A:Yes. It can work with all the software in the market, such as Gerber, PAD, Lectra etc. We also have our own driver, so even you don’t have these software, you can use it too.
Q:If I make the payment, how long will it take to deliver the machine?
A:It will take 3 days to test the machine, when it is done we ship machine to you.
Q:How long is the warranty?
A:The warranty is one year. In this one year, if there are some accessories broken down(Does not include man-made damage), we will send you new and free accessories.
Read before inquiry.
Thank you very much for visiting our website. Please provide the following information when sending an inquiry.
1. Please tell us what kinds of plotters you need. Inkjet plotter or inkjet cutter plotter or flatbed cutter plotter.
2.Tell us what size do you need. Universal sizes are 1.2m, 1.6m, 1.8m. If you need other size, we also can customize it for you.
3.Let us know how many you need. The more you buy, the better price you will get.
